PROXMOX: THE "DO OVER" BUTTON

Prerequisites

• An older PC/small server with virtualization (Intel VT‑x / AMD‑V) — Proxmox host
• Proxmox VE ISO on a USB
• Ubuntu Server 24.04 LTS ISO (for the Portainer VM)
• Basic home network with DHCP and a reserved/static IP for the host

1) Install Proxmox VE

1. Boot from the Proxmox ISO and follow the installer.
2. Set a static IP for the host (adjust later via Netplan if needed).
3. After reboot, open the web UI at https://<proxmox-ip>:8006 and accept the cert.

sudo sed -i 's/^deb/#deb/g' /etc/apt/sources.list.d/pve-enterprise.list
echo "deb http://download.proxmox.com/debian/pve bookworm pve-no-subscription" | sudo tee /etc/apt/sources.list.d/pve-no-subscription.list
sudo apt update && sudo apt -y full-upgrade

2) Create the Portainer VM (Ubuntu Server)

1. Upload the Ubuntu ISO to local: ISO Images in Proxmox.
2. Create VM: 2 vCPU, 4–8 GB RAM, 32–64 GB disk (tune as needed).
3. Install Ubuntu and set a static/reserved IP (e.g., 10.20.0.251 in my lab).
4. SSH in from your workstation to finish setup.

3) Install Docker & Portainer (inside the VM)

Use the convenience script for Docker, then run the Portainer Server:

curl -fsSL https://get.docker.com | sudo bash
sudo usermod -aG docker $USER

sudo docker volume create portainer_data
sudo docker run -d   -p 8000:8000 -p 9443:9443   --name portainer   --restart=always   -v /var/run/docker.sock:/var/run/docker.sock   -v portainer_data:/data   portainer/portainer-ce:latest

Open https://<portainer-vm-ip>:9443 and create the admin user.

4) Add More Docker Environments (Agents on other VMs)

On each additional VM/host you want Portainer to manage, run the agent:

sudo docker run -d   -p 9001:9001   --name portainer_agent   --restart=always   -v /var/run/docker.sock:/var/run/docker.sock   -v /var/lib/docker/volumes:/var/lib/docker/volumes   -v /:/host   portainer/agent:2.33.0

Then in Portainer → Environments → Add environment → Agent, enter the VM’s IP and port 9001.

Snapshots & Backups = the “Do‑Over” Button

1. Before a big change, take a Proxmox VM snapshot.
2. Try your change. If it goes sideways, roll back instantly.
3. Schedule nightly VM backups to another disk or NAS.

Scale Out the Proxmox Cluster

When you outgrow one box, add another node and join it to the cluster.

# On the first (master) node
pvecm status

# On the new node, join the cluster
pvecm add <master-node-ip>

Troubleshooting Gotchas

• Portainer agent can’t connect: open 9001/tcp, verify routes/DNS.
• Proxmox GUI 502 / cert issues: systemctl restart pveproxy pvedaemon pvestatd.
• Storage missing in GUI: check /etc/pve/storage.cfg types/syntax.
• No‑sub nag: use the no‑subscription repo (see above).

Secure Remote Access with Cloudflare Tunnel (Zero Trust)

Expose your Proxmox and Portainer GUIs safely to the internet using Cloudflare Tunnel—no open ports on your router, and protected by Cloudflare Access (SSO + MFA). We’ll install cloudflared on a small Linux VM (or your Portainer VM) and proxy traffic to internal services.

1) Install cloudflared

curl -fsSL https://pkg.cloudflare.com/cloudflare-main.gpg | sudo tee /usr/share/keyrings/cloudflare-main.gpg >/dev/null
echo "deb [signed-by=/usr/share/keyrings/cloudflare-main.gpg] https://pkg.cloudflare.com/cloudflared $(. /etc/os-release && echo $VERSION_CODENAME) main" | sudo tee /etc/apt/sources.list.d/cloudflared.list
sudo apt update && sudo apt install -y cloudflared

2) Authenticate and Create a Tunnel

cloudflared tunnel login
# Complete auth in browser; selects your Cloudflare account/zone
cloudflared tunnel create homelab-tunnel

3) DNS: Public Hostnames → Tunnel

Create CNAMEs in Cloudflare that point to the tunnel UUID (the login flow can add these automatically). Example hostnames:

• proxmox.weitzman.info → internal https://proxmox.lan:8006
• portainer.weitzman.info → internal https://portainer.lan:9443

4) Configure Ingress Rules

Create /etc/cloudflared/config.yml with upstreams. Proxmox uses HTTPS with a self-signed cert, so add noTLSVerify: true for that origin only.

tunnel: homelab-tunnel
credentials-file: /etc/cloudflared/UUID.json  # replace with your tunnel UUID filename

ingress:
  - hostname: proxmox.weitzman.info
    service: https://10.20.0.201:8006
    originRequest:
      noTLSVerify: true   # Proxmox self-signed cert
  - hostname: portainer.weitzman.info
    service: https://10.20.0.251:9443
    originRequest:
      noTLSVerify: true   # if Portainer uses self-signed
  - service: http_status:404

5) Run as a Service

sudo mkdir -p /etc/cloudflared
sudo cp ~/.cloudflared/*.json /etc/cloudflared/   # copy the tunnel UUID creds
sudo chown -R root:root /etc/cloudflared
sudo cloudflared service install
sudo systemctl enable --now cloudflared

6) Lock It Down with Cloudflare Access

In the Cloudflare dashboard → Zero Trust → Access → Applications:

1. Create an Application for proxmox.weitzman.info (type Self-hosted).
2. Require SSO (e.g., Google/Microsoft) and enable MFA policy for your email(s).
3. Optionally allow-list your home ASN/country/IP for extra checks.
4. Repeat for portainer.weitzman.info.

7) Verify

systemctl status cloudflared
cloudflared tunnel list
cloudflared tunnel ingress validate
curl -I https://proxmox.weitzman.info
curl -I https://portainer.weitzman.info

This isn’t just about making things work — it’s about making them repeatable, recoverable, and scalable.
